VOE20515585 Turbocharger Volvo EC160B EC180B EC210B Excavator

VOE20515585 S200G Turbocharger for Volvo EC210B D6D Engine

The VOE20515585 / 20515585 S200G turbocharger is supplied for Volvo D6D diesel engine applications. It is commonly checked for Volvo EC160B, EC180B, EC210B, EW145B, EW160B, EW180B, EW200B and L60E equipment repair. This page should focus on the VOE20515585 turbocharger direction and should not be mixed with VOE20459239 or VOE22329371 turbocharger pages.

This replacement turbocharger is used to restore boost pressure, improve intake air volume and support stable engine output when the old turbocharger has weak boost, oil leakage, abnormal noise, black smoke, damaged wheel blades or excessive shaft play. Before ordering, the old turbocharger tag, engine model and removed sample photos should be checked to confirm the correct housing, flange and oil line layout.

Main Part Number and Ref Cross

The main part number is VOE20515585. The number 20515585 may also appear without the VOE prefix in buyer searches, purchase records or supplier listings. Ref Cross numbers such as 318706, 319303 and 318680 can be used for inquiry matching. Final confirmation should still be based on the old turbocharger nameplate, Volvo D6D engine information and physical sample comparison before shipment.

Part Number: VOE20515585 / 20515585

Ref Cross: 318706 / 319303 / 318680

Turbo Model: S200G / S200 series turbocharger

Engine Model: Volvo D6D / Deutz BF6M2012C diesel engine

Main Application: Volvo EC210B excavator

Related Application: Volvo EC160B, EC180B, EW145B, EW160B, EW180B, EW200B, L60E and related D6D engine applications, verify by old turbo tag and sample photos

Fitment Confirmation Notes

For Volvo EC160B, EC180B and EC210B applications, do not confirm the turbocharger by machine model alone. The same machine family can use different turbocharger arrangements depending on engine version, production range and previous repair history.

Step 1 - Turbo Tag: Check for VOE20515585, 20515585, 318706, 319303, 318680, S200G or S200 on the old turbocharger tag.

Step 2 - Engine Plate: Confirm Volvo D6D or Deutz BF6M2012C from the engine plate or service record.

Step 3 - Machine Model: Confirm EC160B, EC180B, EC210B, EW145B, EW160B, EW180B, EW200B, L60E or the actual Volvo equipment model.

Step 4 - Housing Layout: Compare compressor housing, turbine housing, outlet direction, flange type and actuator position.

Step 5 - Oil Line Position: Confirm oil inlet, oil outlet, return line direction and pipe clearance before shipment.

Repair and Replacement Signs

A worn VOE20515585 turbocharger can cause low boost pressure, black smoke, weak acceleration, abnormal turbo noise, oil leakage, damaged compressor wheel or excessive shaft clearance. Before installing a replacement turbocharger, the air intake, exhaust and lubrication systems should be inspected to reduce the risk of repeat failure.

Low Boost: Check intake leakage, compressor wheel damage, boost hose condition and exhaust restriction.

Black Smoke: Check air filter restriction, low boost pressure, intake pipe leakage and fuel injection condition.

Oil Leakage: Check oil feed line, oil return line, crankcase ventilation and turbo bearing clearance before replacing the turbocharger.

Abnormal Noise: Check shaft play, compressor wheel contact, turbine wheel damage and foreign object impact marks.

Repeat Failure Risk: Check dirty oil, blocked oil return, poor air filter sealing and remaining debris inside the intake pipe before starting the engine with the new turbocharger.

Installation Notes

Before installation, clean the air intake pipe, exhaust connection and oil line area. Remove old gasket material, carbon deposits and loose debris that may enter the turbocharger. Replace damaged gaskets and inspect the air filter, oil filter and engine oil condition during turbocharger replacement.

Prime the turbocharger with clean engine oil before first startup. After installation, let the engine idle briefly and check for oil leakage, exhaust leakage, abnormal turbo sound, smoke, boost response and oil pressure before returning the machine to working load.

FAQ

Is VOE20515585 the main part number for this product?

Yes. VOE20515585 is the main part number for this Volvo D6D S200G turbocharger direction. The number 20515585 can also be used for inquiry matching.

Can 318706 be used as Ref Cross?

Yes. 318706 can be used as a Ref Cross reference for this VOE20515585 turbocharger direction. Final matching should still be confirmed by the old turbo tag and sample photos.

Is this turbocharger for Volvo EC210B?

Yes. This turbocharger can be checked for Volvo EC210B applications when the old turbocharger number, Volvo D6D engine model and removed sample match this product direction.

Can this turbocharger be checked for EC160B or EC180B?

Yes. It can be checked for Volvo EC160B and EC180B applications when the turbo tag, engine model and physical housing layout match this VOE20515585 / S200G direction.

What should I provide before ordering?

Please provide the old turbocharger part number, turbo nameplate photo, engine model, equipment model and clear photos of the removed turbocharger.
