VOE20460945 Turbocharger for Excavator Volvo EC140B EC135B

VOE20460945 S100 Turbocharger for Volvo EC140B D4D Engine

The VOE20460945 / 20460945 S100 turbocharger is supplied for Volvo D4D and Deutz BF4M2012C diesel engine applications. It is commonly checked for Volvo EC140B, EC135B, L50E, BL60, BL61, BL70, BL71 and related Volvo equipment repair. This product page should focus on the VOE20460945 / S100 turbocharger direction.

This replacement turbocharger is used to restore boost pressure, improve intake air volume and support stable engine output when the old turbocharger has weak boost, black smoke, oil leakage, abnormal noise, damaged wheel blades or excessive shaft play. Before ordering, the old turbocharger tag, engine model and removed sample photos should be checked to confirm the correct housing, flange and oil line layout.

Main Part Number and Ref Cross

The main part number is VOE20460945. The number 20460945 may also appear without the VOE prefix in buyer searches, purchase records or supplier listings. Ref Cross numbers such as VOE21147467, 21147467, 04258205KZ, 04254537KZ, 318166, 318279 and 4258205 can be used for inquiry matching. Final confirmation should still be based on the old turbocharger nameplate, engine model and physical sample comparison before shipment.

Part Number: VOE20460945 / 20460945

Ref Cross: VOE21147467 / 21147467 / 04258205KZ / 04254537KZ / 318166 / 318279 / 4258205

Turbo Model: S100 / S100-008H series turbocharger

Engine Model: Volvo D4D / Deutz BF4M2012C diesel engine

Related Engine: Volvo Penta TD420VE / TAD420VE / TAD620VE application direction

Machine Application: Volvo EC140B, EC135B, L50E, BL60, BL61, BL70, BL71 and related equipment applications, verify by old turbo tag and sample photos

Fitment Confirmation Notes

For Volvo EC140B, EC135B and L50E applications, do not confirm the turbocharger by machine model alone. The same machine family can use different turbocharger arrangements depending on engine version, production range and previous repair history.

Step 1 - Turbo Tag: Check for VOE20460945, 20460945, VOE21147467, 21147467, 04258205KZ, 04254537KZ, 318166, 318279 or S100 on the old turbocharger tag.

Step 2 - Engine Plate: Confirm Volvo D4D, Deutz BF4M2012C, TD420VE, TAD420VE, TAD620VE or the actual engine model from the engine plate.

Step 3 - Machine Model: Confirm EC140B, EC135B, L50E, BL60, BL61, BL70, BL71 or the actual Volvo equipment model.

Step 4 - Housing Layout: Compare compressor housing, turbine housing, outlet direction, flange type and actuator position.

Step 5 - Oil Line Position: Confirm oil inlet, oil outlet, return line direction and pipe clearance before shipment.

Repair and Replacement Signs

A worn VOE20460945 turbocharger can cause low boost pressure, black smoke, weak acceleration, abnormal turbo noise, oil leakage, damaged compressor wheel or excessive shaft clearance. Before installing a replacement turbocharger, the air intake, exhaust and lubrication systems should be inspected to reduce the risk of repeat failure.

Low Boost: Check intake leakage, compressor wheel damage, boost hose condition and exhaust restriction.

Black Smoke: Check air filter restriction, low boost pressure, intake pipe leakage and fuel injection condition.

Oil Leakage: Check oil feed line, oil return line, crankcase ventilation and turbo bearing clearance before replacing the turbocharger.

Abnormal Noise: Check shaft play, compressor wheel contact, turbine wheel damage and foreign object impact marks.

Repeat Failure Risk: Check dirty oil, blocked oil return, poor air filter sealing and remaining debris inside the intake pipe before starting the engine with the new turbocharger.

Installation Notes

Before installation, clean the air intake pipe, exhaust connection and oil line area. Remove old gasket material, carbon deposits and loose debris that may enter the turbocharger. Replace damaged gaskets and inspect the air filter, oil filter and engine oil condition during turbocharger replacement.

Prime the turbocharger with clean engine oil before first startup. After installation, let the engine idle briefly and check for oil leakage, exhaust leakage, abnormal turbo sound, smoke, boost response and oil pressure before returning the machine to working load.

FAQ

Is VOE20460945 the main part number for this product?

Yes. VOE20460945 is the main part number for this Volvo D4D S100 turbocharger direction. The number 20460945 can also be used for inquiry matching.

Can 04258205KZ be used as Ref Cross?

Yes. 04258205KZ can be used as a Ref Cross reference for this S100 turbocharger direction. Final matching should still be confirmed by the old turbo tag and sample photos.

Is this turbocharger for Volvo EC140B?

Yes. This turbocharger can be checked for Volvo EC140B applications when the old turbocharger number, engine model and removed sample match this VOE20460945 / S100 direction.

Can this turbocharger be checked for EC135B or L50E?

Yes. It can be checked for Volvo EC135B and L50E applications when the turbo tag, engine model and physical housing layout match this VOE20460945 / S100 direction.

Should VOE20515585 or VOE22329371 be added to this page?

No. VOE20515585 and VOE22329371 belong to different Volvo turbocharger directions and should not be used on this VOE20460945 product page.

What should I provide before ordering?

Please provide the old turbocharger part number, turbo nameplate photo, engine model, equipment model and clear photos of the removed turbocharger.
