11401-E0201 Engine Cylinder Block for Hino J08E Diesel Engine

11401-E0201 J08E Cylinder Block Overview

The 11401-E0201 engine cylinder block is designed for Hino J08E six-cylinder diesel engine applications, including selected Kobelco SK330-8 and SK350-8 excavators. It provides the main structural housing for the cylinder bores, crankshaft, oil passages, coolant passages and engine mounting surfaces.

This cylinder block has a gross weight of 153 kg. The supplied configuration should be confirmed from the current product photos because plugs, covers and other fitted components may vary between production batches.

Fitment Confirmation

Before ordering, compare the original cylinder block number and confirm the engine model, machine model and machine serial number. Machine model alone may not be sufficient because different engine configurations can be used within the same excavator series.

For identification support, provide the original block number, engine nameplate, excavator serial number and clear photos of the existing block. The mounting faces, oil passages, coolant passages and threaded connections should match the original component.

Checks Before Engine Assembly

The deck surface, cylinder bores, main bearing housing, oil galleries, coolant passages, core plugs, threads and mounting faces should be cleaned, measured and inspected by a qualified engine workshop before assembly.

Use the correct bearings, liners, pistons, gaskets and tightening specifications for the exact J08E engine configuration. All oil and coolant passages must be free of machining residue and transportation debris before the engine is assembled.

FAQ

How do I confirm that 11401-E0201 fits my engine?

Confirm the J08E engine model and compare the original cylinder block number. The machine serial number, engine nameplate and photos of the old block should also be checked before ordering.

Which excavator models use this J08E cylinder block?

The 11401-E0201 cylinder block is commonly associated with Kobelco  SK260-8, SK330-8, SK350-8, SK380-8 excavators equipped with the Hino J08E engine. Exact fitment still depends on the engine and machine configuration.

What should be inspected before assembling the engine?

Check the cylinder bores, deck surface, main bearing housing, threaded holes, oil galleries and coolant passages. Professional cleaning and dimensional inspection are required before installation.

What is the warranty period?

The warranty period is 6 months. The engine block must be inspected and assembled by qualified personnel using the correct components and technical specifications.
